분석용 엑스선
스펠만은 분석용 엑스선 분야를 위한 광범위한 표준 및 맞춤형 제품 포트폴리오를 갖춘 세계 최고의 엑스선용 고압발생기 공급업체입니다. 스펠만은 엑스선관 제조업체와 긴밀하게 협력하여 대부분의 산업용 엑스선을 다양한 시장 용도로 구동할 수 있는 솔루션을 제공합니다. 이 범위에는 휴대용 XRF 시스템용 저전력 모듈과 벤치탑용 고출력 솔루션 및 표준 단독 XRF/XRD 다목적 연구기기가 포함됩니다. 맞춤법 엑스선 생성기에는 기존의 엑스선 및 Micro-Focus 엑스선원을 구동하기 위해 필요한 경우 접지 기준 또는 부동 정밀 필라멘트 및 그리드가 포함됩니다. 모든 제품은 까다로운 사용 환경에서 견고하고 안정적인 동시에 정확한 성능 요구사항을 제공하도록 설계되었습니다.
- 60kV
- Output Power 3kW-4kW
- Ideal for Common XRD & XRF X-Ray Tubes
- Solid Encapsulation Ensures Maintenance-Free Operation
- Auto Ramp of the HV Emission Current to Preset Values
- OEM Customization Available
- Output Voltages from 40kV to 320kV
- Output Power 300W, 600W and 1200W
- Bipolar Outputs in a Single Unit
- Compact & Lightweight
- USB, Ethernet and RS-232 Standard Interfaces
- CE Compliant, UL Recognized
- Output Voltages from 20kV-160kV
- Output Power 300W, 600W and 1200W
- Hot Anode or Hot Cathode X-Ray Tube Capable
- USB, Ethernet and RS-232 Standard Interfaces
- CE Compliant, UL Recognized and RoHS Compliant
- User Programmable Ramping and Arc Detect Feature
- Output Voltage 100kV
- Output Power up to 1200W
- Compact & Lightweight Modular Unit
- USB, Ethernet and RS-232 Standard Interfaces
- User Programmable Ramping and Arc Detect Feature
- CE Compliant
- 50kV with 50 or 75 Watt Max
- 65kV with 65 Watt Max
- Floating Integrated Filament Supply
- Local and Remote Emission Control
- Optional Digital Interface
- Output Voltage 50kV at 50 Watt or 75 Watt Max
- Output Voltage 65kV at 65 Watt Max
- Adjustable Integrated Filament Supply
- Local and Remote Emission Control
- CE Marked, UL Recognized
- Output Voltages from 1kV to 70kV
- Output Power 120W
- Low Stored Energy
- UL Recognized and CE compliant
- OEM Customization Available
- Output Voltages from 1kV to 70kV
- EMI/RFI Input Filter
- Internal 10V Ref and Output Inhibit Via TTL Signal
- OEM Customization Available
- Output Voltage from 1kV-160kV
- Output Power 300W, 600W AND 1200W
- Compact & Lightweight
- USB,Ethernet and RS-232 Standard Interfaces
- CE Compliant, UL Recognized
- Output Voltage from 1kV to 60kV
- Output Power 60W
- Low Stored Energy
- OEM Customization Available
- Output Voltage 50kV with 50 Watt or 75 Watt Max.
- Output Voltage 65kV with 65 Watt Max.
- Adjustable Isolated Filament Supply
- Local and Remote Emission Control
- RS-232, Ethernet, & USB Standard
- Output Voltage 50kV, 65kV and 80kV
- Output Power 100W
- Adjustable Ground Isolated Filament Supply
- Overvoltage & Short Circuit Protection
- Local and Remote Emission Control
- RS-232, Ethernet, & USB Standard
- Integrated X-Ray Tube and Control Electronics in One Compact Assembly
- Standard RS-232 Digital Interface Offers Access to Diagnostics and Operating Logs
- Standard Windows Test GUI
- 7 Micron Focal Spot for Narrow Beam
- 8 Micron Focal Spot for Wide Beam
- 10mm/14mm Spot to Window Spacing Provides High Geometric Magnification
- Output Voltages to 60kV
- Output Power 600 W-1.2 kW
- Integrated Floating Filament Supply; "Hot Cathode"
- Negative Polarity
- Local & Remote Programming
- Output Voltage -20V to -10kV
- Output Power 5W
- Integrated Floating Filament Supply
- Low Ripple
- OEM Customization Available
- Output Voltages to 130kV
- Output Power 3 W-260 W
- Ground Referenced Filament Supply
- “Hot Anode”, Positve Polarity
- Local & Remote Programming
- Output Voltage 4kV to 10kV
- Output Power 10W
- Integrated Ground Referenced Filament Supply
- Low Ripple
- OEM Customization Available
- Output Voltage 160kV
- Output Power 80 W-640 W
- Floating Filament
- Internal Grid Power Supply (80W Model)
- Closed-loop Emission Control
- OEM Customization Available
