Analytical X-Ray

Spellman is a world-leading provider of X-Ray Generators, with a vast portfolio of standard and custom product offerings for Analytical X-Ray applications. We work closely with X-Ray tube manufacturers to ensure solutions are available to drive most tubes for a variety of market applications.

Our range includes low-power modules for handheld and portable XRF systems, higher power solutions for bench top and stand-alone XRF/XRD multi-purpose research instruments, and Micro-Focus Monoblocks® for high-resolution X-Ray inspection applications.

Spellman X-Ray Generators feature ground reference or floating precision filaments and grids, where required, to drive traditional X-Ray and Micro-Focus X-Ray sources. All products are designed to deliver exacting performance requirements while being robust and reliable in what can be a harsh application environment.

Where a standard product might not meet your exact needs, we can provide customized designs for OEM applications.



DIFFRACTION • FLUORESCENCE • MICROFOCUS

X-Ray Generators for Diffraction (with floating filament output)
Series
Power
Voltage Range
5W
0kV - 10kV
50W - 75W
50kV - 65kV
80W - 640W
160kV
300W - 1.2kW
40kV - 320kV
300W - 1.2kW
20kV - 160kV
600W - 1.2kW
30kV - 60kV
1.2kW
100kV
3kW - 4kW
60kV
DXM Series

X-Ray Generators for Fluorescence (with ground referenced filament output)
Series
Power
Voltage Range
3W - 260W
30kV - 130kV
10W
4kV - 10kV
50W - 75W
50kV - 65kV
50W - 75W
50kV - 65kV
100W
50kV - 80kV
300W - 1.2kW
20kV - 160kV
3kW - 4kW
60kV
DF / FF Series

Monoblocks® for Microfocus (with Integrated X-Ray Tube)
Series
Power
Voltage Range
20W - 50W
35kV - 80kV
4W - 65W
20kV - 130kV
uXRB130P65

Other General Purpose High Voltage Power Supplies (without filament supply)
Series
Power
Voltage Range
4W - 30W
0kV - 6kV
4W - 30W
8kV - 40kV
10W
1kV - 30kV
10W
1kV - 30kV
20W
1kV - 20kV
60W
1kV - 60kV
60W - 125W
8kV - 20kV
300W - 1.2kW
1kV - 160kV
PCM Series
